TVector< TRing > Class Template Reference
[Algebra objects, Vectors and Matrices]

Template vector class. May filled with elements of TRing. Vectorsize is shrinked to size_t. More...

#include <TVector.h>

Collaboration diagram for TVector< TRing >:

Public Types
typedef TRing::ElementType	TNum
	TRing element type.
Public Member Functions
Constructors, Destructor

	TVector (size_t _size, const TRing *_ring, string _name="unnamedVector")
	Creates a zero TVector of size size with elements in _ring. (vector[i] = TNum::Zero, i is in 0,..,(size-1).
template<class _istream >
	TVector (const TRing *_ring, _istream &_vectorStream, string _name="unnamedVector")
	Creates TVector from a stream, with elements in _ring. Currently only integer entries are supported. Required stream format style is like : {1,22,33,...}.
	TVector (string _vectorStr, const TRing *_ring, string _name="unnamedVector")
	Creates TVector from a string, with elements in _ring. Currently only integer entries are supported. Required string format style is like : {1,22,33,...}.
virtual	~TVector ()
properties

size_t	getSize () const
	get vector size
string	getName () const
void	setName (string _name)
const TRing *	getRing () const
initialising

void	fillZero ()
	fill all elements with TNum::Zero
void	randomInit (long *_pRandomSeed)
	Init all entries with random TRing elements. _pZufallSeed has to point to a random seed, which is used by ran2() random generator randomInit. Only implemented for (ring1->getEpsPrecision==0).
value access

TNum &	operator[] (const size_t pos)
TNum	getVal (const size_t _pos) const
	_pos is 0-based!
const TNum &	getConstValRef (const size_t _pos) const
	_pos is 0-based!
TNum &	getValRef (const size_t _pos)
	_pos is 0-based!
void	setVal (const size_t _pos, const TNum _z)
	_pos is 0-based!
void	setValByRef (const size_t _pos, const TNum &_z)
	_pos is 0-based!
operators

bool	isZero () const
	checks if vector is zero
bool	isNotZero () const
	checks if vector is zero
bool	operator== (TVector &vec) const
bool	operator!= (TVector &vec) const
IO

void	outputAsMatrix (ostream &_os)
	output vector in Macaulay style ( "name = value ; " )
Protected Member Functions
Construction

template<class _istream >
void	createFromStream (_istream &_vectorStream)
	/// Reads a vector from a stream. Currently, createFromStream() works only for vectors with integer elements. Required format style is {1,22,33,...}
Safety

void	checkBounds (size_t pos) const
Private Attributes
const TRing *	ring
	pointer to an object with operations on TRing elements TNum.
size_t	size
	vector dimension
TNum *	data
	vector data
string	name
	object name

Detailed Description

template<class TRing>
class TVector< TRing >

Todo:

add static ring pointer to TNum class?

operator[] implementieren?

Definition at line 25 of file TVector.h.

Member Typedef Documentation

template<class TRing>

typedef TRing::ElementType TVector< TRing >::TNum

Definition at line 28 of file TVector.h.

Constructor & Destructor Documentation

template<class TRing >

TVector< TRing >::TVector	(	size_t	_size,
		const TRing *	_ring,
		string	_name = `"unnamedVector"`
	)			`[inline]`

Parameters:

	_size	vector size
	_ring	a ring operating on TNum-numbers.
	_name	name for the current object

Definition at line 12 of file TVector.cpp.

References TVector< TRing >::data, TVector< TRing >::fillZero(), and TVector< TRing >::size.

Here is the call graph for this function:

template<class TRing >

template<class _istream >

TVector< TRing >::TVector	(	const TRing *	_ring,
		_istream &	_vectorStream,
		string	_name = `"unnamedVector"`
	)			`[inline]`

Definition at line 88 of file TVector.cpp.

template<class TRing >

TVector< TRing >::TVector	(	string	_vectorStr,
		const TRing *	_ring,
		string	_name = `"unnamedVector"`
	)			`[inline]`

Definition at line 100 of file TVector.cpp.

template<class TRing >

TVector< TRing >::~TVector ( ) [inline, virtual]

Definition at line 110 of file TVector.cpp.

References TVector< TRing >::data.

Member Function Documentation

template<class TRing >

void TVector< TRing >::checkBounds ( size_t pos ) const [inline, protected]

Definition at line 120 of file TVector.cpp.

References TVector< TRing >::size.

Referenced by TVector< TRing >::getConstValRef(), TVector< TRing >::getVal(), TVector< TRing >::getValRef(), TVector< TRing >::operator[](), and TVector< TRing >::setVal().

template<class TRing >

template<class _istream >

void TVector< TRing >::createFromStream ( _istream & _dataStream ) [inline, protected]

Todo:

implement StreamIn-Operator for TNum !;

nur istream verwenden, und statt <iostream> nur <iosfwd> im header einbinden

auftretende Fehler werden nicht

Definition at line 37 of file TVector.cpp.

References countElements(), countGroups(), TVector< TRing >::data, extractChar(), extractNextBracedData(), TVector< TRing >::ring, and TVector< TRing >::size.

Here is the call graph for this function:

template<class TRing >

void TVector< TRing >::fillZero ( ) [inline]

Todo:: die for-Schleifen-Initialisierungen durch std::fill ersetzen...

Definition at line 136 of file TVector.cpp.

References TVector< TRing >::data, and TVector< TRing >::size.

Referenced by TVector< TRing >::TVector().

template<class TRing >

const TRing::ElementType & TVector< TRing >::getConstValRef ( const size_t _pos ) const [inline]

Definition at line 198 of file TVector.cpp.

References TVector< TRing >::checkBounds(), and TVector< TRing >::data.

Here is the call graph for this function:

template<class TRing>

string TVector< TRing >::getName ( ) const [inline]

Definition at line 69 of file TVector.h.

References TVector< TRing >::name.

template<class TRing>

const TRing* TVector< TRing >::getRing ( ) const [inline]

Definition at line 71 of file TVector.h.

References TVector< TRing >::ring.

template<class TRing >

size_t TVector< TRing >::getSize ( ) const [inline]

Definition at line 129 of file TVector.cpp.

References TVector< TRing >::size.

Referenced by nCenterFocus::CenterFocusExperiment< variant >::liftTest_performSingleTest(), TVector< TRing >::operator!=(), TMatrix< TRing >::operator*(), TVector< TRing >::operator==(), and TMatrix< TRing >::TMatrix().

template<class TRing >

TRing::ElementType TVector< TRing >::getVal ( const size_t _pos ) const [inline]

Definition at line 178 of file TVector.cpp.

References TVector< TRing >::checkBounds(), and TVector< TRing >::data.

Referenced by Matrix3D< TMatrix2D >::computeFrontalMatrixBasis(), TMatrix< TRing >::getRowBasis(), TVector< TRing >::operator!=(), TMatrix< TRing >::operator*(), TVector< TRing >::operator==(), and TMatrix< TRing >::TMatrix().

Here is the call graph for this function:

template<class TRing >

TRing::ElementType & TVector< TRing >::getValRef ( const size_t _pos ) [inline]

Definition at line 188 of file TVector.cpp.

References TVector< TRing >::checkBounds(), and TVector< TRing >::data.

Referenced by nCenterFocus::CenterFocusExperiment< variant >::liftTest_performSingleTest().

Here is the call graph for this function:

template<class TRing >

bool TVector< TRing >::isNotZero ( ) const [inline]

Definition at line 239 of file TVector.cpp.

References TVector< TRing >::data, and TVector< TRing >::size.

Referenced by Matrix3D< TMatrix2D >::computeFrontalMatrixBasis(), TMatrix< TRing >::getRowBasis(), and TVector< TRing >::isZero().

template<class TRing >

bool TVector< TRing >::isZero ( ) const [inline]

Definition at line 228 of file TVector.cpp.

References TVector< TRing >::data, TVector< TRing >::isNotZero(), and TVector< TRing >::size.

Here is the call graph for this function:

template<class TRing >

bool TVector< TRing >::operator!= ( TVector< TRing > & vec ) const [inline]

Definition at line 264 of file TVector.cpp.

References TVector< TRing >::getSize(), TVector< TRing >::getVal(), and TVector< TRing >::size.

Here is the call graph for this function:

template<class TRing >

bool TVector< TRing >::operator== ( TVector< TRing > & vec ) const [inline]

Definition at line 250 of file TVector.cpp.

References TVector< TRing >::getSize(), TVector< TRing >::getVal(), and TVector< TRing >::size.

Here is the call graph for this function:

template<class TRing >

TRing::ElementType & TVector< TRing >::operator[] ( const size_t pos ) [inline]

Definition at line 149 of file TVector.cpp.

References TVector< TRing >::checkBounds(), and TVector< TRing >::data.

Here is the call graph for this function:

template<class TRing >

void TVector< TRing >::outputAsMatrix ( ostream & _os ) [inline]

Definition at line 279 of file TVector.cpp.

References TVector< TRing >::data, TVector< TRing >::name, and TVector< TRing >::size.

template<class TRing >

void TVector< TRing >::randomInit ( long * _pRandomInit ) [inline]

/

Todo:: : Bessere Konstruktion: randomInit bekommt ein Objekt, welches eine random()-Funktion besitzt. Dann braucht man hier keinen Ring zu speichern! / Bzw. der Ring bekommt eine Random-Fkt (oder die Zahl eine static Random fkt und einen static Ring-Verweis) / Noch besser, wenn TNum einen Verweis auf den Ring enthält! /

Definition at line 216 of file TVector.cpp.

References TVector< TRing >::data, random(), TVector< TRing >::ring, and TVector< TRing >::size.

Here is the call graph for this function:
